21700*1 Cell PC Pins Battery Holder

  • 21700*1 Cell PC Pins Battery Holder
  • 21700*1 Cell PC Pins Battery Holder
  • 21700*1 Cell PC Pins Battery Holder
  • 21700*1 Cell PC Pins Battery Holder
  • 21700*1 Cell PC Pins Battery Holder
Model No.︰21700*1-THM
Brand Name︰BeiLaMoo
Country of Origin︰China
Unit Price︰US $ 0.63 / pc
Minimum Order︰100 pc
Share on:

 Total 6 Related Items
Prev12345Next

Product Description

Part Number:

21700*1-THM

Dimension:

82.5x25x15.6mm

Holder Material:

High Temp NL 66 or NL46,UL 94V-0

Color:

Black

Contacts:

 0.35mm 304 Stainless Steel Spring Temper,Nickel Plated

Temperature Range:

 -60ºF to +290ºF (-50ºC to +145ºC)

Standards:

RoHS Compliant

FEATURES:

Low profile surface mount holder for Cylindrical Lithium and alkaline batteries

UL 94V-0 heat resistant nylon housing well suited for reflow soldering

Battery installation and removal does not require tools

Securely holds battery in place

Polarity clearly marked for orientation

Accomodates cells with or without built-in PCB protection circuits

Gold-plated Phosphor Bronze contacts assure low contact resistance and are readily solderable

Ideal for both lead free solder and traditional solder process



Payment Terms︰TT
